Product Introduction
Construction concrete mixer trucks, also known as cement mixer trucks, are mainly used for on-site concrete mixing and transportation, and are widely used in construction sites, highway construction, bridge engineering and other fields. Concrete mixer trucks have the advantages of uniform mixing, convenient transportation, and high work efficiency. They can meet the needs of on-site concrete mixing and transportation and improve engineering construction efficiency.
Product Parameters
| Overall dimensions | 9780mm*2496mm*3990mm(Length*Width*Height) |
| Deadweight | 13950kg |
| Payload | 35000kg |
| Front overhang | 1500mm |
| Rear Overhang | 2880mm |
| Wheelbase | 4000mm+1400mm |
| Wheelbase (front/rear) | 2022mm/1830mm |
| Chassis | |
| Chassis brand | SINOTRUK HOWO |
| Chassis model | ZZ1257N4048W，Drive type 6×4 |
| Cab | HW76，Left-hand drive, air conditioning, one bed |
| engine | SINOTRUK WD615.47，371Horsepower (273 kW), Euro II emission standard, 4-stroke direct injection diesel engine, 6 cylinders in-line, water-cooled, turbocharged and intercooled, displacement 9.726 liters |
| Gearbox | HW19710，Speed number: 10 front and 2 rear |
| Steering | Germany ZF8098, steering system pressure 18MPa |
| Rear axle | HC16 double axle, rated load 2×13 tons, speed ratio 5.73 |
| Tires and wheels | Wheel 9.0-22.5; Tire 12R22.5, 10 pieces; Spare tire rack: with one spare tire |
| brake | Service brake: dual circuit air pressure brake; Parking brake: spring energy, rear wheel compressed air operation; Auxiliary brake: engine exhaust brake |
Application areas
1. Construction projects: Concrete mixer trucks are widely used in construction projects, including house construction, road construction, bridge construction, etc. In these projects, mixer trucks can mix raw materials on site, produce concrete that meets the requirements of the project, and transport it directly to the construction site, greatly improving construction efficiency.
2. Water conservancy projects: In water conservancy projects, mixer trucks can be used for concrete construction of dams, reservoirs, drainage ditches, etc.
3. Urban facilities: Mixer trucks can also be used in the construction of urban underground facilities, municipal roads, city squares, etc.
Packaging and transportation
We have established trade cooperation with many countries in the world. Our professional vehicles have been successfully sold to Southeast Asia, the Middle East, Africa, South America and other regions. The experienced team selects the most suitable transportation methods for different customers, including container, Rolls-Royce and bulk transportation, balancing safety and economic costs.
FAQ
1.Q: Which markets do you export your vehicles to?
A: Europe, North and South America, Southeast Asia, Africa, Oceania, Middle East countries, etc.
2.Q: What information should I tell you if I want to get a quotation?
A: Please tell us your purpose, road conditions, cargo type, cargo tonnage, trailer size, quantity, etc. The more information you provide, the more accurate the model and price you will get.
3.Q: Can we print our own brand on the vehicle?
A: Totally acceptable.
4.Q: Can we visit your factory before buying?
A: We welcome you to visit our factory at any time, and we will show you our production line.
5.Q: How can I get the price of your vehicle?
A: You can contact us through any contact information. Our personalized service staff will reply you within 24 hours.
